Description

53-762-102 Fowler Shore D Durometer

Fowler’s Portable Durometer is just right for testing the hardness of flexible materials such as rubber and plastics. These gages conform to shore scales.

Features include…

• Manufactured in accordance with DIN, ASTM, ISO and JIS specifications, two styles are available in both analog and digital readout.
• A scale unit to fit a wide variety of applications.
• Test pieces should have a thickness of at least .20″/5mm to provide accurate readings that conform to Shore D hardness scales.
• Penetrator: Blunt taper 30°
• Shore Scale: D
• Graduation: 1 Shore
• The test piece size should be smooth and have sufficient area to be able to support the base of the hardness tester.
• Includes reference test block, operating instructions and fitted case.
• Optional bench stand available.

Applications include…

• Soft and natural rubber products
• Neoprene and polyesters
• Soft P.V.C.
• Leather
• Thiokol
• Nitril rubbers, wax, felt and more.
