Description

303-717-13A-S Mitutoyo Vertical Optical Comparator PJ-H30 8″ x 4″ & Stand

Mitutoyo’s PJ-H30A Vertical, High Accuracy Optical Comparator

Mitutoyo’s newly designed Vertical Optical Comparator with high NA lenses provides drastically brighter and clearer screen images during surface illumination.

The Easy-to-Read digital counters are located near the projection screen, thereby minimizing strain associated with excessive movement. A digital angle display eliminates the need to perform complex calculations. The included Digital Readout Protractor screen facilitates angle measurements.

The three-lens mounting turret includes a 10X lens as standard.

• 5X, 20X, 50X & 100X lenses are available.

A floating table makes measuring quick and easy.

PJ-H30A2010B features include the following…

• 12″ Diameter Screen
• 8″ x 4″ / 200mm x 100mm Measuring Range
• 0.0001″ / 0.001mm Resolution
• 13.8″ x 11″ Table Size
• 4.1″ / 105mm Max Workpiece Height
• 22lbs Max Workpiece Load

This package includes the following…

• PJ-H30 Main Unit with 10X Lens
• Mitutoyo Optical Comparator Stand

FREE Freight Anywhere in the Continental USA

High Visibility Digital Display

Since the digital counter (XY axes and angle) built into all models as standard uses a high-intensity LED and a large-character display, it secures high visibility unaffected by the environment. In addition to zero-setting and direction change, the data output of each counter value adopts the highly versatile RS-232C.
